Fiber Optic Fusion Splice Protector
splice protector sleeves provide
mechanical and environmental protection for
fusion splices of single and ribbonized fiber.
- clear outer heat-shrink material
- low temperature hot melt adhesive to encapsulate the splice
- stainless steel rod for single fiber splices and a ceramic rod for ribbonized fiber splices to ensure proper alignment and rigidity.
sleeves for single fibers are ideal for protecting single fusion splices of primary and secondary tight or semi-tight coated fibers.
sleeves for multiple fibers are ideal for protecting mass fusion splices of ribbons with two to twelve fibers.
sleeves are guaranteed to be compatible with the full range of Tyco Electronics fiber management systems and organizers.
|
|
|
|
|
FOSC Trays with Optical Components
Single-mode wideband couplers/splitters are branching devices available in a wide rang of styles and sizes to split and combine light.
These devices are integrated into Tyco Electronics' FOSC range of fiber-optic splicing trays. This allows for easy integration in enclosures,
wall-mount boxes, or FDFs.
- Consistent performance
- Low optical loss
- Low polarization sensitivity
- Excellent mechanical and environmental characteristics
- Fast installation and commissioning
- Combining and splitting light signals
- Central office/headend
- Aerial pole
- LAN
- Network monitoring
- FTTH PON-NETWORKS
|
|
|
|
|
Description: Kit for installing multiple small cables ina single 450 port.
SOQ:5
| Kit Name |
|
Part Number |
| FOSC-ACC-450-MULTIDROP |
|
F94503-000 |
A. Installation Instructions
B. Multidrop kit(s)
|
|
| Drop Diameter |
|
No. of Drops per port |
| 0.27" or less |
|
4 |
| 0.28" to 0.35" |
|
3 |
| 0.36" to 0.43" |
|
2
|
|
|
|
|
|
Buffer Tube Access Tool
This revolutionary tool provides quick and easy access to fibers
every time, even in the hands of inexperiences installers. The
precision-ground blade and special inserts hold the tube
firmly in place in the shaving channel, ensuring that only the
tube wall is cut, and not the fibers. The planing action keeps the
buffer tube gel contained, providing cleaner access. Thick
gauge steel alloy construction and a hardshell tots case permit
years of continuous field use.
- Inserts to support a wide variety of buffer tube sizes
- Quick, easy, trouble-free access to fibers
- Virtually no damage to fibers
- Precision-machined tube guide channel and blade
|
|
|
|
|
|
